Coil Voltage:
24V dc
Contact Configuration:
DPDT
Mounting Type:
PCB Mount
Maximum Switching Current AC:
2 A
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V
Series:
HFD4
Maximum Switching Power DC:
60 W
Latching:
No
Length:
10mm
Depth:
6.5mm
Height:
5.65mm
Dimensions:
10 x 6.5 x 5.65mm
Terminal Type:
Through Hole
Switching Current:
2A
Number of Poles:
2
Isolation Coil To Contact:
2.5kV ac
Electrical Life:
100000 Operations
Contact Material:
Gold Plated
Maximum Switching Power AC:
62.5VA
Relay Switching Classification:
Subminiature Signal Relay
Life:
1 x 10^8 cycles
Features:
Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available
Maximum Operating Temperature:
+85°C
Coil Power:
140mW
Minimum Operating Temperature:
-40°C
Operating Temperature Range:
-40 → +85°C
Coil Resistance:
2800Ω
