Coil Voltage:
5V dc
Contact Configuration:
DPDT
Mounting Type:
Surface Mount
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V
Series:
IM
Maximum Switching Power DC:
60 W
Length:
10mm
Latching:
No
Depth:
6mm
Height:
5.65mm
Dimensions:
10 x 6 x 5.65mm
Terminal Type:
Through Hole
Number of Poles:
1
Switching Current:
2A
Application:
Access & Transmission Equipment, Consumer Electronics, Industrial Controls, Measurement & Test Equipment, Medical Equipment, Modems, Office & Business Equipment, Optical Network Terminals, Telecommunication
Coil Resistance:
178Ω
Maximum Switching Power AC:
62.5VA
Life:
100000000 (Mechanical) operations, 2500000 (Electrical) operations
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
Isolation Coil To Contact:
2kV
Coil Power:
140mW
Operating Temperature Range:
-40 → +85°C
Relay Switching Classification:
General Purpose Relay
Features:
Bifurcated Contacts
Contact Material:
Gold Plated
Standards Met:
UL 508 File No. E 111441
