Coil Voltage:
24V dc
Contact Configuration:
DPDT
Mounting Type:
PCB Mount
Maximum Switching Current AC:
0.5 A
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
125V
Maximum Switching Voltage DC:
110V
Maximum Switching Power DC:
30 W
Series:
HFD31
Length:
14.5mm
Latching:
No
Depth:
9mm
Height:
5.4mm
Dimensions:
14 x 9 x 5mm
Terminal Type:
Through Hole
Switching Current:
2A
Number of Poles:
2
Relay Switching Classification:
Subminiature Signal Relay
Electrical Life:
100000 Operations
Coil Power:
140mW
Maximum Operating Temperature:
+70°C
Isolation Coil To Contact:
1.5kV rms
Operating Temperature Range:
-40 → +70°C
Coil Resistance:
2800Ω
Minimum Operating Temperature:
-40°C
Life:
1 x 10^8 cycles
Maximum Switching Power AC:
62.5VA
Features:
Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available
Contact Material:
Gold Plated
